サイズ：S/M/L
カラー：Mango, Matt Black（ 2color）
長時間にわたるマウンテンバイクライドに適したバイクは、上りも軽く、下りは安全に楽しくなければならない。無尽蔵な楽しみがトレイルのどこにでもあるべきだ。したがって、我々はトレイルに適したMETA TRAIL のフルサスジオメトリと、こだわりのパーツを組み合わせてこれを実現。妥協は許さない。シングルトラックNO.1 モデルの異名をかけて、V4 は走り続ける。
| MODEL | META TRAIL V4.2 ORIGIN |
|---|---|
| Frame | META TR V4.2 650b Travel 130mm |
| Shock | ROCKSHOX DELUXE RT, 210x50mm, rebound, plateform 2 positions |
| Fork | ROCKSHOX REVELATION RC 140mm, solo air,, boost |
| Headset | RIDE ALPHA ZS44/ZS56 |
| Stem | RIDE ALPHA, Alloy 2014 Forged, 50mm, 0° Angle, Φ31,8mm |
| Bar | RIDE ALPHA, Alloy 7075, double butted, 30mm rise, 780mm, Φ31,8mm |
| Grips | COMMENCAL Lock on, Φ32mm, soft compound |
| Brakes | SRAM LEVEL, 200mm/180mm |
| Shifters | SRAM NX 1x11sp |
| ChainGUIDE | / |
| Rear Mech | SRAM NX, 11sp |
| Bottom Bracket | SRAM GXP Press Fit BB92 |
| Cranks | SRAM NX X-Sync, 32t, boost 170mm on S/M and 175mm on L/XL |
| Chain | SRAM PC 1110 |
| Cassette | SRAM PG 1130, 11-42, 11sp |
| Rims | WTB STP i25, 32 holes, double wall, tubeless ready, 25mm inner |
| Hubs | FORMULA, 32 holes, sealed bearings |
| Spokes | PILLAR Spokes, Stainless steel, 1.8mm black, Nylock |
| Tires | MAXXIS DHF 650x2,3 EXO TR front and MAXXIS MINION SS 650x2,3 EXO TR rear |
| Seatposts | RIDE ALPHA, 31,6mm, no offset, 350mm |
| Saddle | RIDE ALPHA SuperLight foam, Cr-Mo rails |
| Accesories | Down tube protector, chainstay protector ,seatstay protector, chainstay cable guide |
| Sizes | S/M/L |
| Colors | Mango / Matt Black (2 colors) |
| Weight | 13.9kg |
| FRAME SIZE | S | M | L |
|---|---|---|---|
| SEAT TUBE LENGTH | 400 | 440 | 490 |
| SEAT TUBE ANGLE | 74° | 74° | 74° |
| HEAD TUBE ANGLE | 66.5° | 66.5° | 66.5° |
| HEAD TUBE LENGTH | 110 | 115 | 120 |
| WHEEL BASE | 1144 | 1166 | 1193 |
| TOP TUBE LENGTH | 580 | 607 | 627.3 |
| CHAIN STAY LENGTH | 437 | 437 | 437 |
| BOTTOM BRACKET HEIGHT | -25 | -25 | -25 |
| FORK LENGTH | 522 | 522 | 522 |
| STAND-OVER HEIGHT | 680 | 690 | 700 |
| Height adaptation | 153-168 | 168-178 | 178-188 |
