EL CAMINO650B

価格(税別)¥94,800 完成車

サイズ:S/M/L
カラー:Matt Black



SPECIFICATIONS

MODEL EL CAMINO 650B
Frame aluminium formed 6061with Rear Carrier Bolt Base(M/L/XL)/without Rear Carrier Bolt Base(S)
Shock /
Fork RST BLAZE T, 650b, 100mm on S and 120mm M/L/XL, 1"1/8 steerer
Headset SEMI-INTEGRATED ZS44/ZS44
Stem EL CAMINO, Alloy Forged, 60mm, Φ31,8mm
Bar ALLOY 6061 BAR, 700mm on XS/S and 720mm M/L/XL, 25mm rise
Grips COMMENCAL, Soft Compound
Brakes TEKTRO HD-M 285, Hydraulic disc brake 180mm/160mm, with reach adjustment
Shifters SRAM X4, 3x8sp
ChainGUIDE
Rear Mech SRAM X4, 3sp / SRAM X3, 8sp
Bottom Bracket SRAM Powerspline
Cranks SRAM S200 22/32/42 170mm on XS/S/M and 175mm on L/XL
Chain YABAN S8
Cassette SRAM PG 820, 11-32, 8sp
Rims ALEXRIMS TD 19, double wall, 32 holes, 19mm inner
Hubs FORMULA, 32 holes
Spokes PILLAR spokes steel 1,8mm black - brass 12mm black
Tires MAXXIS Ardent 650x2,25
Seatposts RIDE ALPHA, 31,6mm, no offset, 350mm
Saddle COMMENCAL, El Camino, Steel Black Rails, Soft Padding
Accesories Pedals, chainstay protector
Sizes S/M/L/XL
Colors Matt black
Weight 13.7kg

GEOMETRY

MODEL NAME EL CAMINO
FRAME SIZE S M L XL
SEAT TUBE LENGTH 400 440 490 520
SEAT TUBE ANGLE 73° 73° 73° 73°
HEAD TUBE ANGLE 68° 68° 68° 68°
HEAD TUBE LENGTH 110 110 120 130
WHEEL BASE 1060 1080 1105 1130
TOP TUBE LENGTH 565 585 610 635
CHAIN STAY LENGTH 435 435 435 435
BOTTOM BRACKET HEIGHT -50 -48 -48 -48
FORK LENGTH 485 505 505 505
STAND-OVER HEIGHT 725 755 785 815
Height adaptation 153-168 168-178 178-188 188-
  1. 1SEAT TUBE LENGTH
  2. 2SEAT TUBE ANGLE
  3. 3HEAD TUBE ANGLE
  4. 4HEAD TUBE LENGTH
  5. 5WHEEL BASE
  6. 6TOP TUBE LENGTH
  7. 7CHAIN STAY LENGTH
  8. 8BOTTOM BRACKET HEIGHT
  9. 9FORK LENGTH
  10. 10STAND-OVER HEIGHT
