サイズ：S/M/L
カラー：Brushed, Black Anodized (2colors)
| MODEL | FRAME SUPREME DH V4.2 |
|---|---|
| Frame | SUPREME V4 650b alloy 6066 hydroformed 220mm travel |
| Shock | / |
| ISCG05 | ISCG05 |
| Rear Axle | included (150x12mm P1.0) |
| Sizes | S/M/L |
| Colors | Brushed/Red Stripe, Brushed/Orange Stripe, Brushed, Black Anodized (4 colors) |
| Weight | 4.5kg |
| FRAME SIZE | S | M | L |
|---|---|---|---|
| SEAT TUBE LENGTH | 400 | 400 | 400 |
| SEAT TUBE ANGLE | 66 | 66 | 66 |
| HEAD TUBE ANGLE | 63 | 63 | 63 |
| HEAD TUBE LENGTH | 108 | 108 | 108 |
| WHEEL BASE | 1163 | 1192 | 1222 |
| TOP TUBE LENGTH | 548 | 575 | 600 |
| CHAIN STAY LENGTH | 425 | 425 | 425 |
| BOTTOM BRACKET HEIGHT | -5 | -5 | -5 |
| FORK LENGTH | 590 | 590 | 590 |
| STANDOVER HEIGHT | 703 | 703 | 703 |
| Height adaptation | 153-170 | 168-180 | 178-190 |
